INFRARED SENSING (PIR) MODULE HC-SR5050 - HAITRONIC
Product Code: HS0870
Product Description:
| Specification |
|
|
| Operating Voltage Range |
|
4.5 to 20V DC |
| Static current |
|
<60uA |
| Output level |
|
High 3.3V |
| |
|
Low 0V |
| Trigger |
|
Repeatable trigger (default) |
| Delay time |
|
8 seconds + -30% (default) |
| PCB Dimensions |
|
10 x 23mm |
| Sensor Lens Diameter |
|
10mm |
| Total length (PCB & Sensor) |
|
35mm |
| Induction angle |
|
<100 degree cone angle |
| Induction distance |
|
3 meters |
| Working temperature |
|
-20°C to +80°C |
| Net weight |
|
2g |
