INFRARED SENSING (PIR) MODULE AM312 - HAITRONIC
Product Code: HS0869
Product Description:
| Specification |
|
|
| Operating Voltage Range |
|
4.5 to 12V DC |
| Static current |
|
<0.1mA |
| Output level |
|
High 3.3V |
| |
|
Low 0V |
| PCB Dimensions |
|
10 x 8mm |
| Sensor Lens Diameter |
|
12mm |
| Total length (PCB & Sensor) |
|
19mm |
| Induction angle |
|
<100 degree cone angle |
| Induction distance |
|
3 meters |
| Working temperature |
|
-20°C to +80°C |
