JST-PH HOUSING 2-WAY 2.0mm
Product Code: 14301980
Product Description:
| Number of Positions |
|
2 |
| Number of Rows |
|
1 |
| Pitch |
|
2 mm |
| Contact Gender |
|
Socket |
| Gender |
|
Receptacle |
| Termination Type |
|
Crimp |
| Mounting Type |
|
Cable Mount |
| Body Orientation |
|
Straight |
| Housing Material |
|
Polyamide |
| Combustibility Class |
|
UL 94 V-0 |
| Approvals |
|
CSA, TUV, UL |
| Current Rating |
|
2 A |
| Voltage Rating |
|
100 VAC / VDC |
| Operating Temperature |
|
-25°C to +85°C |
| Dimensions |
|
|
| A |
|
1.5 mm |
| B |
|
4.5 mm |
| Manufacturer Part Number |
|
PHR-2 |
| Suitable insert |
|
14301989 |
| Manufacturer Part Number |
|
BPH-002T-P0.5S |
| Mates With PCB Header |
|
14301944 |
| Datasheet |
|
Available |
