MRBF TERMINAL FUSE BLOCK 30 TO 300 AMP FOR SCREWCAP FUSES
Product Code: BS5191
Product Description:
- Compact, high-amp fuse—appropriate for DC Main, inverter, windlass, and bow thruster circuit protection
- Provides high current protection in tight space constraints
- Ignition protected when used with Blue Sea Systems' MRBF Terminal Fuse
- Isolated stud design uses standard M8 hardware and permits stacking of terminals
- Insulating cap prevents accidental shorts
- Accepts 5∕16" ring terminals
- Mounts on 3/8” terminal studs
- Fuse sold separately
| Ignition Protected |
|
No |
| Maximum Amperage |
|
300A ** |
| Number of Fuse Positions |
|
1 |
| Maximum Voltage |
|
58V DC |
| Maximum Torque |
|
75 in-lb (8.47 Nm) |
| Terminal Stud |
|
M8 (5/16") |
| Weight |
|
0.16lb (0.07 kg) |
| Manufacturer |
|
Blue Sea |
| Manufacturer Part Number |
|
5191 |
**Maximum amperage ratings are dependent on use of appropriately sized fuses and wire for a given application.
