BATTERY ISOLATOR 350A 48V DC
Product Code: BS9004E
Product Description:
| Battery Switch |
|
Battery Disconnect |
| Switch Type |
|
Single Circuit ON-OFF |
| Color |
|
Red |
| Switch Positions |
|
2 |
| Battery Combine |
|
No |
| Alternator Field Disconnect |
|
Yes |
| Maximum Voltage |
|
48V DC |
| Continuous Rating |
|
350A |
| Intermittent Rating |
|
600A (5 min) |
| Cranking Rating |
|
1200A 30 sec |
| Battery Inputs |
|
1 |
| Cable Clearance For 4/0 AWG Cables |
|
1.10in (27.94 mm) |
| Cable Size to Meet Ratings |
|
4/0 AWG (120mm²) |
| Mounting Holes |
|
Accept 1/4" (M6) Screw |
| Terminal Stud Size |
|
3/8"-16 (M10) |
| Terminal Stud Torque |
|
140 in-lb (15.82 Nm) |
| Weight |
|
1.30lb (0.59 kg) |
