XT30 PLUG AND SOCKET PCB MOUNTING
Product Code: HS3510
Product Description:
| Connector Type |
|
XT30 Plug & Socket |
| Mounting |
|
PCB |
| Orientation |
|
Horizontal |
| Body Material |
|
Gold-plated copper & PA |
| Internal Material |
|
Nylon / PA |
| Color |
|
Yellow |
| Internal Resistance |
|
0.7mΩ |
| Rated Current |
|
15A |
| Peak Current |
|
30A |
| Rated Voltage max |
|
220VDC |
| Operating Temperature |
|
-20 to 120°C |
| Recommend Soldering |
|
480°C for 4sec |
| Weight |
|
1.7g / Pair |
| Manufacturer |
|
Amass |
