SWITCH PUSH MOMENTARY SPST OFF-(ON) MINIATURE
Product Code: HS1777
Product Description:
| Contact Configuration |
|
SPST (Normally Open) |
| Number Of Poles |
|
1 |
| Switching Function |
|
OFF - (ON) |
| |
|
Momentary |
| Actuator Type |
|
Pushbutton |
| Switch Color |
|
Red |
| Contact Current |
|
1 A @ 250 VAC |
| |
|
3 A @ 125 VAC |
| Contact Voltage max |
|
250 VAC |
| Contact resistance max |
|
50m Ohms |
| Button Diameter |
|
5.8 mm |
| Cut Out Size (Diameter) |
|
7 mm |
| Depth Behind Panel |
|
15 mm |
| Body Color |
|
Black / Silver |
| Termination Type |
|
Soldering Connection |
| Mounting Type |
|
Panel Mount |
| Switch Material |
|
ABS / Phenolic |
| Manufacturer Part Number |
|
PBS-110 |
