RELAY AUTO 12VDC 30/40A SPCO
Product Code: 12-0121Z22
Product Description:
| Contacts |
|
1 Change Open (SPCO) |
| Coil voltage |
|
12 VDC |
| Coil resistance |
|
80 Ohms |
| Switching current |
|
|
| @ 13.5 VDC |
|
30 / 40 A (NC / NO) |
| @ 27 VDC |
|
10 / 20 A (NC / NO) |
| Connections coil |
|
Balde 6.3 mm |
| Connections contact |
|
Blade 6.3 mm |
| Dimensions L x W x H |
|
27 x 27 x 38 mm |
