RELAY AUTO 24VDC 100/120A SPCO
Product Code: 12-21170
Product Description:
| Contacts |
|
1 Change Open (SPCO) |
| Coil voltage |
|
24 VDC |
| Coil resistance |
|
246 Ohms |
| Switching current @ 24 VDC |
|
|
| Continuous |
|
100 / 120 A (NC / NO) |
| Intermittent |
|
120 / 160 A (NC / NO) |
| Connections coil |
|
Balde 6.3 mm |
| Connections contact |
|
M8 Studs with Nut |
| Dimensions L x W x H |
|
46 x 46 x 45 mm |
| Manufacturer Part Number |
|
21170 |
