RELAY AUTO 24VDC 50A SPNO WITH RESISTOR
Product Code: 12-21163
Product Description:
| Coil Voltage |
|
24 VDC |
| Contact Function |
|
SPNO (Single Pole Normally Open) |
| Coil + Snubber Resistance |
|
322 Ohm |
| Snubber Resistor |
|
Yes |
| Switching Current @ 24 VDC |
|
50 A (NO) |
| Mounting Type |
|
Plug-In Mount |
| Connections coil |
|
Blade 6.3 mm |
| Connections contacts |
|
Blade 9.5 mm |
| Dimensions (L x W x H) |
|
25.7 x 28.5 x 24.8 mm |
| Manufacturer Part Number |
|
21163 |
