RELAY AUTO MINI 12VDC 25A SPNO WITH DIODE
Product Code: 12-21135
Product Description:
| Coil Operating voltage |
|
12 VDC |
| Coil Resistance |
|
91.5 Ohms |
| Back EMF Diode ** |
|
Yes |
| Coil Connection |
|
Terminal 1 Positive |
| |
|
Terminal 2 Negative |
| Contact Rating @ 12 VDC |
|
25A |
| Configuration |
|
One Normally Open (SPNO) |
| Coil Connections |
|
4.8 mm |
| Contact Connections |
|
6.3 mm |
| Dimensions (L x W x H) |
|
23.4 x 15.4 x 25.6 mm |
| Manufacturer Part Number |
|
21135 |
** Polarity across coil must be observed (1 - Positive / 2 - Negative)
