SWITCH REED N/O 0.5A
Product Code: HR0309-56
Product Description:
| Contact form |
|
1N/O (Normally Open) |
| Contact material |
|
Ruthenium |
| Switching capacity |
|
10VA |
| Switching voltage max. |
|
100V |
| Switching current max. |
|
0.5A |
| Contact resistance |
|
<100mOhms |
| Contact capacitance |
|
0.7pF |
| Operate / Release time |
|
1ms / 0.4ms |
| Pull-in sensitivity |
|
10-35AT |
| Dimensions |
|
|
| Body |
|
14.2 x 2.3mm |
| O/A length |
|
44.7mm |
