TIMER MODULE RELAY OUTPUT - DELAY 'ON'
Product Code: HR0214-94A
Product Description:
| Operation type |
|
Delay ON Trigger timer |
| Supply voltage |
|
4 to 16 volts |
| Connections |
|
Screw terminals |
| Trigger input |
|
5 volts |
| Timer duration (adjustable) |
|
0 to 10 seconds |
| Relay output |
|
SPCO (1 change over) |
| Contact current (30VDC / 240VAC) |
|
10A |
| Dimensions |
|
67 x 21 x 18mm |
