RELAY PCB MOUNTING SPCO 12VDC 16A
Product Code: 346031
Product Description:
| Nominal Voltage |
|
12 VDC |
| Operating Voltage |
|
9.6 to 13.2V DC |
| Contact Form |
|
1 Change Over (SPCO) |
| Contact Material |
|
Silver Cadmium Oxide |
| Coil Resistance |
|
270 Ohms |
| Coil Consumption |
|
500mW |
| Contact Rating |
|
16A @ 30Vdc |
| |
|
16A @ 250Vac |
| Coil To Contact Voltage |
|
5 KV |
| Operating Temperature max |
|
+60°C |
| Mechanical Lifetime |
|
3 x 10^7 |
| Electrical Lifetime |
|
2 x 10^5 |
| Dimensions (L x D x H) |
|
30.0 x 12.5 x 25mm |
| Pin Spacing |
|
5mm |
